Version 8.5 Getting Started GuideA Guide to Integrating a RightFax Fax Server with a OneBox Telephony Server

Getting Started Guide 6 EN/LZT 108 5826/6 R2B Ericsson  November 2002 Document Storage Requirements The RightFax server expects fax cover pages to

RightFax 8.5 EN/LZT 108 5826/6 R2B Ericsson  November 2002 7 Most PCL 5 printer drivers have an option to limit output resolution to 300 dpi if th

Getting Started Guide 8 EN/LZT 108 5826/6 R2B Ericsson  November 2002 Installing the Feature Key The feature key activates the features that have b

RightFax 8.5 EN/LZT 108 5826/6 R2B Ericsson  November 2002 9 Specifying the RightFax Name and LAN Protocol On the System tab in the OneBox Configu

Getting Started Guide 10 EN/LZT 108 5826/6 R2B Ericsson  November 2002 Configuring the OneBox Dialing Plans Both Faxtext and fax messaging use dial

RightFax 8.5 EN/LZT 108 5826/6 R2B Ericsson  November 2002 11 Creating a “Source” Mailbox for Delivering Faxes You must create a mailbox that the

Getting Started Guide 12 EN/LZT 108 5826/6 R2B Ericsson  November 2002 Installing or Creating Cover Pages For your fax application to work properly

RightFax 8.5 EN/LZT 108 5826/6 R2B Ericsson  November 2002 13 Integrating RightFax with OneBox To ensure that the RightFax server can communicate

Getting Started Guide 14 EN/LZT 108 5826/6 R2B Ericsson  November 2002 Assigning the Telephony Server to One or More WorkServers You must assign th

RightFax 8.5 EN/LZT 108 5826/6 R2B Ericsson  November 2002 15 Assigning Channel Capability to the BoardServers The Board Configuration screen in t

Getting Started Guide ii EN/LZT 108 5826/6 R2B Ericsson  November 2002 Edition Note This is the first edition of the RightFax Version 8.5 Getting S

Getting Started Guide 16 EN/LZT 108 5826/6 R2B Ericsson  November 2002 If, however, you are using a card such as the Brooktrout TR-114-I4C, you m

RightFax 8.5 EN/LZT 108 5826/6 R2B Ericsson  November 2002 17 Setting Up the Default User This section shows how to take advantage of the Default

Getting Started Guide 18 EN/LZT 108 5826/6 R2B Ericsson  November 2002 Identification Tab and Inbound Routing Tab of the Edit User screen When sett

RightFax 8.5 EN/LZT 108 5826/6 R2B Ericsson  November 2002 19 Figure 7. Inbound Routing Tab of Edit User screen Complete these fields.

Getting Started Guide 20 EN/LZT 108 5826/6 R2B Ericsson  November 2002 Table 2. Inbound Routing Tab of Edit User screen Field Description Routing

RightFax 8.5 EN/LZT 108 5826/6 R2B Ericsson  November 2002 21 Setting Up Users in OneBox You can use the Fax User tab in each OneBox subscriber’s

Getting Started Guide 22 EN/LZT 108 5826/6 R2B Ericsson  November 2002 This page left blank intentionally.

RightFax 8.5 EN/LZT 108 5826/6 R2B Ericsson  November 2002 iii Table of Contents Introduction ...

Getting Started Guide iv EN/LZT 108 5826/6 R2B Ericsson  November 2002 This page left blank intentionally.

RightFax 8.5 EN/LZT 108 5826/6 R2B Ericsson  November 2002 1 Introduction Fax functionality for a OneBox telephony server is supplied through an i

Getting Started Guide 2 EN/LZT 108 5826/6 R2B Ericsson  November 2002 Calling for a Bump Code RightFax requires a channel authorization (bump code)

RightFax 8.5 EN/LZT 108 5826/6 R2B Ericsson  November 2002 3 Important Facts You Should Know This section lists known benefits and limitations tha

Getting Started Guide 4 EN/LZT 108 5826/6 R2B Ericsson  November 2002 Setting Up Fax Support on the Telephony Server The Telephony Gateway enables

RightFax 8.5 EN/LZT 108 5826/6 R2B Ericsson  November 2002 5 Reviewing Installation Requirements This section lists the requirements for successfu
