Getting Started Guide

6 EN/LZT 108 5826/6 R2B Ericsson



November 2002

Document Storage Requirements

The RightFax server expects fax cover pages to be stored in Hewlett-Packard’s Printer

Control Language, version 5.0 (PCL 5); this allows it to insert new information to cover

pages when it sends them out. The fax server normally stores Faxtext library documents

and other faxes as Group 3 TIFF bitmap files.

Before setting up a Faxtext application, you will need to make sure that the fax server

platform has enough free disk space for all of the library documents, cover pages, and

subscriber faxes it must store. Table 1 provides guidelines for calculating how many

kilobytes (KB) of space the fax server will need.

Important You must leave at least 50 MB of hard disk space open on the fax server’s working

drive (normally D). If there is less than 50 MB of space on this drive, the fax server

will not be able to send or receive faxes.

Table 1. Estimating fax document storage requirements

Type of Document Space required File Extension

Text documents, as PCL 5 100 KB per page .PCL

Full-page graphics, as PCL 5 350 KB per page .PCL

TIFF documents with Group 3

compression

35 KB per page .TIF

Temporary files 50 MB Not applicable

For example, by the guidelines in Table 1, you could estimate the disk space required

for a document library consisting of 50 cover pages in PCL 5 format, plus 200 pages of

graphics in TIFF format:

50 MB + (50 x 350 KB) + (200 x 35 KB) = 74,500 KB (72.75 MB)

In addition to meeting your current requirements, be sure to leave enough space for

your fax server’s future needs.

Note Many current PCL printer drivers assume that the printer has an output

resolution of 600 dots per inch (dpi) or higher. The fax server can transmit a

page of this resolution, but since the resulting fax cannot be greater than 200

dpi, the original page wastes disk space. For example, each full-page, 600 dpi

PCL 5 page takes up more than one megabyte.
